3MP
S-PTZ1-4G- 3 MP 4G PT Camera
- Description : 3 MP 4G PT Camera
- Model No : S-PTZ1-4G
Features:
- 3MP HD Image, clear and crystal
- 2.5-inch ultra-mini body, plastic material, weatherproof and delicate appearance
- Pan: 0°~260°, Tilt: 0°-90°, support 10 preset positions
- Support FTP, Cloud storage and Local TF card video storage to ensure safe storage of video data
- Support MIC and speaker, two-way audio
- With Infrared and spotlight, support three night vision modes, adjustable to achieve full color at night
- Area motion detection, active defense, when someone appear the alert area, camera will turn on the sound alarm, alarm notification will be pushed on your phone
- Support remote monitoring on mobile phones and PC to check the live situation anytime, anywhere
- IP66 waterproof rating, 4000V lightning protection, anti-surge
- Intelligent lighting control fill light, black and white monitoring, color video
- Humanoid Detection & Humanoid Tracking Feature Available
- Support Onvif & RTSP LAN Only
- Support RTMP
- Specifications
Basic Specification
Resolution
Sensor
Shutter
Lens
Rotation Angle
Day-Night Mode
DNR
Dynamic Range
IR Distance
Compression
Video Compression
Video Compression
Audio Coding Format
Resolution
Frame Rate
Image reversal
Privacy Masking
Back Light Compensation
Network
4G Standard
4G Frequency Band
Ethernet
Alarm
Intelligent Alarm
Alarm Notification
Storage
Interface
Cloud Storage
Onvif
Working Temperature
Power Adapter
3MP
1/3″ CMOS Sensor
Shutter adaptation
4mm
Pan: 0°~260° 20°/S; Tilt: 90° 10°/S
Infrared filter
3D digital noise reduction
Digital WDR
IR 20-30m, spotlight 15-20m (depends on environment)
H.265/H.264
HD/SD, Rate adaptation
AAC/G711A
Main stream: 2304 *1296, Sub stream: 640×360
Max 15fps, frame rate self-adaption
Support horizontal and vertical reversal
Support MAX 4 Zone
Support
LTE-TDD/LTE-FDD/TD-SCDMA/WCDM
LTE-FDD:B1/B3/B5/B8;LTE-TDD:B34/B38/B39/B40/B41; WCDMA:B1/B5/B8
1*RJ 45 Port 10/100 (Auto adept)
Motion detection
Push alarm notification
Micro SD Card (Max 256G)
Support
Support LAN Only
-200C ~ 500C, Working Humidity:<95%(no condensation)
DC 12V1A
