MediSec
Pulse Oximeter – S-OXM1
- Description : Pulse Oximeter
- Model No : S-OXM1
- Blood Oxygen (SpO2)
- Heart Rate (BPM)
- One Key Control
- Energy Efficient
Enquiry
Download Datasheet
- Technical Specifications
- Dimension : 58x32x36mm
- Screen Type : OLED high-end display
- Battery : 2 No (AAA) 1.5V alkaline batteries
- Blood oxygen meas. range : 0 ~ 100% (Resolution is 1%)
- Blood oxygen meas. acur. :70 ~ 100% ± 2% Less than 70% undefined
- Pulse meas. range : 30~250BPM (resolution is 1 BPM)
- Pulse meas. accuracy : ±2BPM or ±23%, whichever is greater
- Sp02 meas. range : 5% ~ 99%
- Sp02 accuracy 1 : +1% in the range of 90% ~ 99% +2% in the range of 70% ~ 89%
- Sp02 Alarm Range : “Consistent with the display range , the set step length is 1%
- Pulse rate alarm range : “Consistent with the display range, the set step length is 5bpm
- Data update cycle : 0.25s ~ 2s
- Sp02 PR average : 8s
- Pulse rate sound : PR tone
- Peak wavelength range : 500nm ~ 100nm
- Maximum optical out power : 150mW
- Pulse rate display : Numeric
