Wireless Camera
Wireless Outdoor Camera : SIP-2HDG-W40
- Description : 4G Outdoor WiFi Camera
- Model No : SIP-2HDG-W40
KEY FEATURES
- Smart HD.264 Compression
- Cloud Technology
- Motion Detection
- Support TF Card
Enquiry
Download Datasheet
- Technical Supports
- Image Sensor : Sony STARVIS 2MP 1/2.8 IMX307 CMOS
- Minimum Illumination : 0.001Lux @(F1.4,AGC ON) ,0 Lux with IR
- Shutter : Self-adaptive shutter
- Lens : 3.6mm,M12
- Day & Night : IR cut filter
- Infrared distance : 30 Meters
- Video Compression : Smart H.264
- Video Compression Standards : Main Profile
- Video Bit Rate : Adaptive bit rate
- Audio Compression Standards : AAC
- Audio Compression Rate: Adaptive Bit-rate
- Audio Compression Rate: Adaptive Bit-rate
- Max. Resolution : HD:1920X1080 SD:640×360
- FPS : 15fps, Network transmission frame rate adaptation
- Image setting : Mirror, flip
- Intelligent alarming : Input: Humanoid detection, Output: Linked custom audio, linked lighting
- Configuration : SmartConfig, AP configuration, Manually
- Port agreement : Cloud privacy aggrement
- General function : Anti flicke, double stream, mirror, password protection, watermark
- Storage interface : Micro SD card(maximum128G)
- Power interface : Φ5.5 round head power interface
- Wireless standard : IEEE802.11b, 802.11g, 802.11n
- Frequency : 2.4 GHz ~ 2.4835 GHz
- Channel bandwidth : Support 20MHz
- Safety : 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
- Transmission rate : 11b:11Mbps,11g:54mbps, 11n:150mbps
- Network : FDD-LTE,TDD-LTE,WCDMA/HSPA+,TD-SCDMA,GSM/GPRS/EDGE
- Frequency band : LTE-B1/B3/B8/B38/B39/B40/B41; WCDMA-2100/900Mhz; TD-SCDMAB34/B39; GSM/GPRS/EDGE-900/1800Mhz
- Transmission Rate : FDD-LTE: Uplink50Mbps / downlink150Mbps, TDD-LTE: Uplink50Mbps / downlink150Mbps, HSPA+: Uplink5.76Mbps / downlink21Mbps, TD-SCDMA: Uplink5.76Mbps / downlink2.8Mbps
- Cloud Service : Available
- APP : Secureye Falcon
- Power : DC12V±10%
- Power Consumption : 12W MAX
