Wireless Camera
IP Dome Wifi Camera: S-IP-3MD-WFA
- Description : 3MP IP Dome IR Camera With WiFi
- Model No : S-IP-3MD-WFA
key Features:
- FHD: 3MP, 1296P(2304’1296P), H.2641 H.265
- Audio: Built-in Mic & Speaker, supports two-way audio
- Lens: 4mm Lens, IR range up to 15m
- Storage: MicroSD card (Max 128GB), Local and FTP storage
- AP Hotspot: With a wireless access point, camera can be connected to phone directly without router
- Alarm: Support Motion detection alarm, phone push alarm
- Onvif: Support Onvif protocol, can work with NVR
- Software: Support Windows PC(HCMS, Onvif NVR, Blue Iris, ispy), Internet Explorer
Enquiry
Download Datasheet
- Technical Spefications
System
- Main Processor : HiSilicon 3516E, High- performance processor
- Sensor : 1/2.7, 3Megapixel progressive scan CMOS
- Image Compression : H264 / H.265 ( Default is H264, can be set H.265 by IE browser )
Lens
- Lens Parameter : Focal length: 4mm, 3MP
- Angle of View : Horizontal: 73°, Vertical: 53.6°, Diagonal: 95,2°
Video
- Resolution : 1296P(2304×1296) / 1080P(1920×1080) / 720P(1280×720) / VGA(640×480)
- Image Frame Rate : Main stream: 3MP(15fps – 25fps) / Sub stream: VGA(25fps)
- Automatic Exposure : Adjust the image automatically to view clearly
- Infrared Mode : Automatic
- Night Visibility : 2 PCS array IR illumination LEDs, IR range up to 15 meters
- Min.Illumination : 0.01 Lux / F1.2 (With IR Illuminator)
- Zoom : App supports 3x digital zoom
- Audio : Built-in Mic & Speaker, supports two-way audio
Alarm
- Alarm : Motion detection alarm
- Alarm Notification : Push alarm notifications to your smartphone
- Advanced Zone Detection : Set customized motion detection zones to control what you’re monitoring
Privacy
- Privacy Protection : System defaults the first user as administrator, other users accessing the camera need administrator’s authorization, otherwise they can’t view it
- Privacy Block :Set up to 4 privacy areas
Network
- Remote Access : P2P
- Ethernet : RJ-45
- Wireless : 2.46 IEEE 802.11 b/gIn, supports WEP, WPA & WPA2 Encryption
- AP Hotspot : With wireless access point, camera can be connected to phone without router
- Protocol : IPV4, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, DDNS, FTP, IP Filter, QoS
- Interoperability : Onvif
Software
- App : iOS &Android
- Windows PC CMS : HCMS, ONVIF Device Manager, Blue Iris, ispy etc.
- Web Browser : Internet Explorer
Record
- Record Mode : Motion detection alarm recording, 7/24 recording
- Record Standard : HD mode(1296P/1080P/720P) / SD mode(360P)
- Storage : MicroSD card (Max 128GB), Local and FTP storage
- Playback : Remote and local record playback
other
- Product Type : Plastic Dome type, indoor use
- Power Supply : DC 12V
- Working Temperature : -10°C — 50°C
- Working Humidity : 10% to 90% RH
- Weight : N.W.:232g, G.W.:420g (Note:Actual Weight Final)
- Accessories : Adaptor, User Manual, Screws, & LAN Cable
- Size : Item size: 118’118900 mm (LxWxH), Packaging size: 152’135909mm (LxWxH)
- Certification : CE, FCC & RoHS
