Hotel Locks
Hotel Door Lock System – S-HL20
- Description : Hotel Lock With Key card & Mechanical key(silver)
- Model No : S-HL20
- Zink Alloy with Solidity Nature
- Mechanical Key Supported
- Free Handle to Prevent External Stress
- Available with NO/NC Ports(Optional)
- 256 Record of Door Opening
- Community, Office Entrance Guard
- Used in: Hotel, Parking Lot, Residence
- Color Option: Brass / Silver
Enquiry
Download Datasheet
- Technical Specification
- Card Type: ID,TEMIC,MF1
- Inductive distance: ≤ cm5
- Power Supply: DC 6V 4pc of No.5 Alkaline Batteries
- Power Consumption: Static Current: ≤ 1A5 μ
- Card Reading Current: ≤ 2m0A
- Lock Opening Current: About 300 mA (last for 0.3s)
- Temperature: -20°C~+70°C
- Humidity: ≤ 95RH%
- Communication Supported: NO/NC
- Lack of Voltage Indication: When the voltage is < 4.8V,there will be a 3 sound and the red LED will light. Furthermore,the lock can still be opened for more than 50 times.
- Application: Hotels, Parking Lot, Residence Community,Office Entrance Guard and so on.
- Specialities: Output Guard, Water Proof And Moisture Proof, Tamper-proof Management Anti-static electricity: >15,000 V, it ensures information inside the lock not missing under the interference of strong static electricity.
